Berylas Podiatry Laser
Product Certificates

Berylas Podiatry Laser – Precision Laser for Nail Fungus & Foot Care

Berylas podiatry laser manufactured by Dimed is an advanced diode laser solution for foot care professionals. With optimal wavelengths, it effectively treats nail fungus, onychomycosis, plantar warts, spider veins, and other podiatric conditions, delivering safe, precise, and comfortable laser treatments. Its portable design, optimized wavelengths and easy-to-use interface make it an ideal solution for podiatry clinics.

Why Berylas Podiatry Laser

Portable design

Compact with modular design, lightweight only 2.1KG, easy to carry

Intuitive interface

Advanced Android software, 7 inches intuitive interface for easy touch

Advanced cooling system

Through hundreds of thermal analysis simulation, it can work continuously at least 4 hours, no overheating problem

Built-in rechargeable battery

Internal lithium battery, can be worked in different treatment scenarios for long working time

Optimal wavelength

Equipped with 980nm/1064nm wavelength, enables deeper tissue penetration with even heat distribution and minimal pigmentation risk

Complete preset protocols

Built-in podiatry treatment protocols streamline workflows and reduce setup time for clinicians

Multi-functional handpiece

Convenient finger switch for true portability, easy replacement for different heads

Internal fiber connector

Fiber connector of the cable is inside the shell, easy to maintain, more durable

Clinical Applications in Laser Podiatry

Berylas podiatry laser emit infrared light with a wavelength of 980nm/1064nm. The laser allows deeper penetration into tissues and reduces the risk of pigmentation changes, without damaging the surrounding tissues. Due to the increased interaction of molecules with the laser, heat is distributed more evenly.

  • Onychomycosis
  • Plantar warts
  • Vascular lesions
  • Intractable plantar keratosis
  • Minor soft tissues surgery (cut, coagulation and vaporization)
  • Podiatric postoperative of hallux-valgus and finger trigger
  • Plantar fascitis
  • Tendinitis aquileia
  • Metatarsalgia and hallux-valgus
Podiatry Laser Treatment

Technical Specifications

Product Berylas Podiatry Laser
Laser Type GaAIAs Diode Laser
Model BERYLAS-10J BERYLAS-30K BERYLAS-15FJ BERYLAS-D4C
Wavelength 980nm 1064nm 810nm+980nm 650nm+810nm+915nm+980nm
Maximum Power 10W 30W 15W+15W 300mW+10W+10W+10W
Operation Mode Continuous Wave, Single or Repeat Pulses
Pulse Duration 10us-3s
Repetition Rate 1Hz-20KHz
IP Degree of Protection Footswich (waterproof): IPX8
Aiming Beam Red Diode Laser of 650nm, Power<5mW
Control Mode True Color Touch Screen (7 inches, High-resolution 1200*1920px)
Transmission System Medical Fibers with SMA905 Connector
Dimensions 160(W)*180(L)*235(H)mm
Weight 2.1Kg

Watch Berylas Podiatry Laser in Action
